Beyond 77: Project planning with an eye to policy

The forward-looking tech-enabled toolkit that’s driving Charlotte’s multimodal future.

The Beyond 77 Corridor Study, facilitated by the Charlotte Regional Transportation Planning Organization (CRTPO) in Charlotte, North Carolina, started with a goal to find ways to reduce congestion and increase multimodal options along and around the 68-mile long, 400+ square-mile study area. That early vision evolved considerably when the agency, at the recommendation of its study consultant, looked beyond just adding more lane miles or vehicular capacity, but through a more comprehensive lens to consider policy and programmatic needs that could enhance mobility in the future across the network.

It’s a broader perspective that resulted in the adoption of the region’s first ever technology enabled corridor evaluation toolkit that comprises strategies and solutions—numbering 286— culled from extensive non-traditional stakeholder coordination and public engagements. This toolkit, called the Strategic Users Implementation Tool (SUIT), facilitated by a customized online application, allows planners, decision-makers, and members of the public to get involved in the overall planning and implementation efforts—and has become a framework that will guide decision making of major transportation projects, programs and concepts along this corridor for the next 30+ years.

Common Intersections

The population of the Charlotte metropolitan area and surrounding regions is expected to nearly double by 2050, a growth that will place a heavy burden on the region’s transportation networks, especially I-77. Beyond 77 was launched in January 2020, with AtkinsRéalis as the lead consultant, to develop effective strategies and solutions for the I-77 corridor moving forward. The six key elements of the study included: congestion management, connectivity within the parallel networks, funding, technology, multimodal systems and land use coordination.

Early on, AtkinsRéalis developed the Lifecycle of Transportation Planning to help guide critical conversations and begin formulating ideas for potential mobility solutions across the key areas of concern with community leaders, stakeholders as well as state and local entities.

Also critical to the success of the Beyond 77 Corridor Study was public participation. For this effort, the AtkinsRéalis team relied on a carefully curated and nontraditional marketing and public engagement plan. The plan targeted specific audiences, ultimately encouraging active participation throughout the study, gathering feedback from local residents through a series of email blasts, public workshops and community forums.

Adam Howell, AICP Senior Director at AtkinsRéalis and consultant team Project Manager, said, “We did not just host public meetings or webinars and hope that people joined. We went to the people. The survey links were blasted regionally using IP targeting and geofencing for social media applications, based on demographics, profession, etc.”

And the ROI of this method proved impressive. CRTPO and AtkinsRéalis received more than 25,000 survey responses during the study—a significant improvement compared to historical public engagement surveys. “The public engagement piece was one of the primary drivers of this project’s success,” Howell added, “as the responses became an essential piece of the strategies and solutions that would emerge. We were able to bring people from all backgrounds together to talk about very complex issues and find solutions.”

To further enhance the review of the public’s feedback, AtkinsRéalis enabled dynamic analysis platforms through the use of PowerBI. These digital dashboards allow for macro or micro analysis based on jurisdiction, demographics, zip code, or even the census block of a particular group of constituents are tied to the public engagement data. It’s an innovation that was paramount in handling the sheer volume of engagement data received and facilitating the final recommendations.

Working closely with the AtkinsRéalis team, CRTPO ultimately adopted the 286 strategies and solutions focused on social, economic and resilient elements as part of the Beyond 77 Corridor Study. Of note, several divisions of the North Carolina Department of Transportation (NCDOT), such as Integrated Mobility and Intelligent Transportation Systems, were involved in the approval of all strategies and solutions that were ultimately selected.

Putting that many strategies and solutions into action required even more help from technology.

Digital Dimensions

Building on the innovations from the engagement data dashboards, AtkinsRéalis created a custom digital framework that was delivered on the client’s request of a flexible planning toolkit.

The SUIT toolkit is built for planners, decision makers and the general public to interact with proposed recommendations while deriving critical high-level information that ranged from communities served to schedule. SUIT is a custom user interface (UI) designed to incorporate graphical databases. These specialized databases are coded to showcase relationships across all strategies and solutions which, in turn, help educate the user on how each strategy or solution may potentially be dependent on one another.

Within SUIT, a user can see any set of strategies and solutions with ties to a city, town, or county as well as a suggested sequence of implementation over time. They can view modes that are expected to benefit from each of the strategies and solutions and view tailored details with comprehensive perspectives for all aspects of implementation.

Planners can even create custom bundles or personalized Work Plans to help foster further dialogue and drive implementation of a chosen strategy or solution over a certain timeframe. By creating custom Work Plans, any individual can explore priorities unique to the jurisdiction or agency they represent and plan for local or regional coordination of implementation needs. This innovative tool helps inform the planner about the level of staff resources that may be necessary, any associated direct costs, and agencies that should be considered for coordination. Howell explained, “The planning tool allows a local planner, for instance, to see how a larger CRTPO effort might influence land use policies in their area down the road—and plan accordingly. It essentially breaks down the traditional silos that exist in the regional planning process. Or it could help planners to collectively work together to benefit regional infrastructure investments, a coordinated effort that would help influence state funding.”

Another strategy is the emerging technology recommendations. In this case, one of the recommendations is Connected/Autonomous Vehicles (C/AVs) & Traffic Data Sharing Apps, a long-term solution under the Emerging Technologies key area. The goal of this strategy is to develop software solutions that enable data sharing, data integration, and data analytics that benefit both the user and the operating entity and improves reliability and journey planning.

This effort ties nicely with the PM-13, Connected/Autonomous Vehicles (C/AV) & Emerging Mobility Technology Policy Development, an effort that stems from the formalization of the Connected/Autonomous Vehicles (C/AVs) Working Group and larger ensuing dialogues. It emphasizes the need for state, regional, and local agencies to consider policy needs applicable for effective incorporation of C/AVs and other mobility-related technologies into existing planning and programmatic functions. Funding Alternative Strategies Tool (FAST) Opportunity

The Beyond 77 team knew that funding strategies would be a necessary and integral piece of the success of the proposed programs and projects. Building on the flexibility of SUIT and the public engagement data dashboards, the team finalized a series of short-term funding strategies that were enabled by state statutes. The strategies were documented in the Funding Alternative Strategies Tool (FAST). FAST can be used to explore six short-term funding alternative strategies across multiple counties within the Charlotte metropolitan area.

“The purpose of the FAST tool is to help leaders and staff start a conversation about what it means to look at funding through a regional lens,” Howell explained. FAST allows users to see how an increase (or decrease) in funding would impact programs over time. The user could input the information to see what monies could be raised based on different forms of funding strategies.

A second component of FAST is a breakdown of where all anticipated funds could be used to facilitate different modes of transportation solutions, such as roadway miles or buses, or this many miles of greenway. Then the user can quickly determine funding allocations for each of those modes.

The funding strategies were developed to inform a series of choices and tradeoffs, analogous to the development and intent of the strategies and solutions. As the Beyond 77 final report notes, “The funding strategies serve as a critical part of the greater dialogue seeking coordination across jurisdictional boundaries to provide solutions to regional needs. The implementation of the strategies and solutions, paired with one or more of the identified funding strategies (and even other regionally coordinate initiatives), will support effective large-scale investment in transportation infrastructure benefitting generations to come.”

Collaborative and Connected The strategies and solutions developed as part of the Beyond 77 Corridor Study are designed to meet multiple objectives that range from safe and equitable mobility options to enhancing freight connectivity. Also, CRTPO sought to ensure that any transportation policies and programs were sensitive to environmental justice and equity.

For instance, one of the strategies includes the implementation of Greenways & Mobility Hubs. This solution recommends the implementation of greenway and multi-use path infrastructure along key corridors to connect to transit stations and mobility hubs, allowing more multi-modal options to connect across the region. To move the region into a more sustainable and equitable future with a range of transportation options, new and safe connections for bicycles and pedestrians must be made to transit investments and areas of high density.

These connections will allow improved utilization of transit investments, benefitting both regional transit operability and individual user’s ability to access them in a safe and useful way. Another strategy example includes Policies for Equity Factors in Planning. This strategy recommends the development of new, optional policy language elements for jurisdictions and organizations to adopt into local planning and project work. This language would seek to effectively define what equitable mobility means across the Charlotte metropolitan area. Equity has become a critical element to consider with all planning functions, beyond standard requirements defined by Federal or State agencies. The Beyond 77 team believes the jurisdictions in the Charlotte metropolitan area have an opportunity to pair equity needs between land use and transportation planning.

Constant collaboration between Beyond 77 and the parallel regional transit plan, CONNECT Beyond, managed by the Centralina Regional Council and the Charlotte Area Transit System helped provide regional transit recommendations that traversed the Beyond 77 study area across multiple transit modes, and strategies and solutions needed to align. Both study teams shared information frequently to ensure that ideas supplemented each other for optimal outcomes.

In summary, Howell noted, “One of the greatest benefits of the Beyond 77 Corridor Study has been the ability to provide tools that enable users to break out and tailor pieces of the proposed solutions and also provide an innovative, comprehensive and flexible suite of implementation elements, from new policies, programs and projects.”

The CRTPO executive director acknowledged the importance of the Beyond 77 study, noting that “The application allows CRTPO, its member jurisdictions and stakeholders to collaboratively develop implementation efforts for these strategies and solutions and understand how they are all related and impact the success of one another. Beyond 77 is one of the nation’s most comprehensive studies of its kind. The outcomes have set us up as an organization to enhance our planning and coordination efforts that will improve mobility along such a critical corridor.”
